AC Moving Iron Sq 72 Panel Ammeters

Name: AC Moving Iron Sq 72 Panel Ammeters
Brand: RADISSON INSTRUMENTS
Price: 240 INR
Availability: InStock

Price 240 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

AC Moving Iron Sq 72 Panel Ammeters Specification

Equipment Type
Panel Ammeter

Resolution
Fine pointer movement for accurate reading

Sensor Type
Moving Iron

Frequency
50/60 Hz

Measurement Range
0 to Full Scale (as per model)

Capacity
72x72mm panel size

Temperature Range
0C to 50C

Power Supply
AC

Power Consumption
Low

Accuracy
Class 1.5

AC Moving Iron Sq 72 Panel Ammeters Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
4000 Pieces Per Month

Delivery Time
1-3 Week

Main Domestic Market
All India

About AC Moving Iron Sq 72 Panel Ammeters

AC Moving Iron Sq 72 Panel Ammeters & Voltmeters

Product Specification

Model	SF 72 / SD 72
Description	Moving iron meter of 90° deflection.
Movement Type	Moving iron spring-mounted jewel bearing suspension
Accuracy	± 1.5% of full scale as per IS 1248
Range	Current (A): 0-1A to 1-100A (Direct), Through CT/1A or /5A for Higher Currents Voltage (V): 0-50V to 0-600V (Direct), Through PT for Higher Voltages
Self Consumption	Ammeters (upto 5A AC) - < 0.6 VA; Voltmeters (upto 500V AC) - < 5Va
Operating Voltage	600V RMS max.
Test Voltage	2.5 time for 1 min. at 50 hz
Construction and Design	According to IS 1248;
Scale	According to DIN 43802
Case/Housing Material	Black Nylon dimensions as per DIN 43700
Bezel	Black Polycarbonate & ABS dimensions as per DIN 43718
Glass Faceplate	Flat Glass, Antiglare and Polycarbonate (shatter proof) on request.
Mounting Fasteners / Clamps	Ergonomic easy mountable clamps and nuts for easy installation on switchboards, panels, Mosaics etc.
Temperature Conditions	-10°C to 55°C, RH<90% (Operating) and
Front Protection	IP52 protection as per IS 2147.IP54 (Optional)

Precision and Reliable Performance

Engineered with Class 1.5 accuracy, the AC Moving Iron Sq 72 Panel Ammeter offers fine pointer resolution for clear and accurate readings. Its moving iron sensor ensures consistent performance across a broad measurement range, making it a dependable choice for precise current measurement in electrical panels.

Versatile and Robust Design

Crafted for compatibility with standard 72x72mm panel cutouts, this ammeter is easy to install and integrates seamlessly into diverse panel setups. The device operates efficiently within temperatures from 0C to 50C and accommodates frequencies of 50/60 Hz, rendering it highly suitable for the Indian industrial environment.

FAQs of AC Moving Iron Sq 72 Panel Ammeters:

Q: How do I install the AC Moving Iron Sq 72 Panel Ammeter into a control panel?

A: To install the ammeter, align it with a 72x72mm panel cutout, secure it using mounting hardware provided, and connect the terminals according to your circuit configuration. Ensure power is off during installation for safety.

Q: What advantages does the moving iron sensor offer in this panel ammeter?

A: The moving iron sensor provides high durability and fine pointer movement, delivering precise current readings with minimum wear. It also works effectively over a wide frequency range, making it versatile for various AC applications.

Q: Where is this panel ammeter most commonly used?

A: This ammeter is commonly installed in industrial electrical panels, switchboards, and power distribution boards, especially in environments requiring reliable current monitoring across facilities in India.

Q: What is the measurement range of this ammeter model?

A: The measurement range extends from zero to the full scale value, which varies based on the specific model selected. This flexibility allows users to choose a model that best fits their current monitoring requirements.

Q: When should I choose this ammeter over a digital alternative?

A: Opt for this ammeter when you need robust performance, straightforward operation, and clearly visible analog readings without reliance on external power supplies or complex electronics, especially in demanding industrial settings.

Q: What is the process for accurate current measurement with this device?

A: Accurate measurement is achieved by proper wiring according to the electrical load, ensuring stable installation, and reading the fine movement of the pointer, which correlates to real-time current values within the specified accuracy class.

Q: What are the benefits of low power consumption in this panel ammeter?

A: Low power consumption reduces overall power load on your system, making the device energy efficient, minimizing heat generation, and contributing to extended lifespan of panel equipment.
